Subway Opal

7,5 x 15 cm | 3” x 6”

Suggested grout: Deko

Weight and Dimensions

Size

7,5 x 15 cm | 3” x 6”
Supplied loose

Thickness

~ 4 mm | 5/32”

Joint

~ 1 mm | 2/48”

Weight

~ 10 kg/m2 | 1.6 Ib/SQF

Data are indicative only as it is a hand-cut product.

Test ASTM

TEST PERFORMED AND REQUIREMENTS

CONCLUSIONS

Range of thickness (ASTM C499)

PASSES

Facial dimensions (ASTM C499)

PASSES

Wedging (ASTM C502)

PASSES

Water absorption (ASTM C373)

PASSES

Thermal shocks (ASTM C484)

PASSES

Bond Strenght (ASTM C482)

PASSES

Crazing (ASTM C424)

PASSES

TEST DATA

UNI EN ISO 10545 (13)
RESISTANCE TO CHEMICAL AGENTS

RESISTANT

ASTM C 484 | UNI EN ISO 10545 (9))
THERMAL SHOCKS RESISTANCE

RESISTANT

UNI EN ISO 10545 (3)
WATER ABSORPTION

NONE

DIN 51094
COLOURS RESISTANCE TO FADING

RESISTANT

UNI EN ISO 10545 (12)
FROST RESISTANCE

RESISTANT

TECHNICAL REQUIREMENT:

For the application in humid zones, use epoxy adhesives and grouts. For further information please contact TREND Group.

Description

The Subway collection is an interpretation of Karma glass, primarily intended as a wall covering material suitable for indoor and outdoor use.

Each 7,5 x 15 cm tile is hand-cut, resulting in the subtle lack of perfect symmetry characteristic of an artisan product. The individual handcrafted glass tiles feature natural shading variations and luminous brilliance.

Available in four different finishes, this collection allows for particular depth effects when mixing the different finishes together. Please note that all product data is indicative only, as it is a hand-cut product.

Supply loose.
